ScanSnap Manager Icon and Operations (for Windows users)
40
ScanSnap Manager Icon and Operations
All operations on the ScanSnap are managed in ScanSnap Manager.
Normally, the ScanSnap Manager icon is added to the taskbar in the lower right of the
Windows desktop. The icon automatically appears on the taskbar when Windows is started
up.
The ScanSnap Manager icon also indicates whether or not ScanSnap Manager is
successfully communicating with the ScanSnap. The appearance of the icon changes
according to the communication status as shown below.
This guide uses examples of power cable connection.
Click this icon to display the menu which you can use to start scanning, change scanning
settings, and check the consumables status.
Status Icon on the Taskbar
Communicating Power cable connection:
USB bus power cable connection:
Not communicating
In Windows 7, the ScanSnap Manager icon is displayed in the menu that appears when you
click in the taskbar.
To have the ScanSnap Manager icon always displayed in the taskbar, drag the icon and drop it
onto the taskbar.

Fujitsu ScanSnap S1300 Specifications

General

Film scanning	No
Color scanning	Yes
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	10 sheets
USB version	2.0
Standard interfaces	USB 2.0
Scan media weight	64 - 104.7 g/m²
Dimensions (WxDxH)	284 x 99 x 77 mm
Power requirements	AC 100 - 240V, 50/ 60 Hz
Non-operating relative humidity (non-condensing)	20 - 80 %
Minimum RAM	512 MB
Minimum storage drive space	2197 MB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	5 W
Power consumption (typical)	9 W
Operating temperature (T-T)	5 - 35 °C
Certification	RoHS

Weight and Dimensions

Depth	99 mm
Width	284 mm
Height	77 mm
Weight	1400 g
