Fujitsu ScanSnap S1300 User Manual

How to Load Documents
28
How to Load Documents
Load the documents in the ScanSnap as follows:
1. Check the number of sheets.
The maximum number of sheets that can be loaded in the ScanSnap is as follows:
For A4-size or smaller paper: A document stack of 1 mm or less
(Ten sheets at 80 g/m
2
or at 20 lb)
2. Fan the documents to prevent paper jam.
1. Hold the documents with both hands and fan them out two or three times as shown
in the figure below.
2. Rotate the documents by 90 degrees and fan them in the same manner.
3. Straighten the edges of documents, and load them in the ScanSnap so
that the top edges of the papers form a step-like pattern.
If you try to scan more sheets than the maximum amount that can be loaded, the
following problems may occur:
z Paper jams may occur during scanning.
z Files may be improperly created due to the excessive file size.
If documents are scanned without their edges aligned, they may get jammed or
damaged.
BackBack
Step-like
pattern
Feeding direction

Fujitsu ScanSnap S1300 Specifications

General

Film scanning	No
Color scanning	Yes
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	10 sheets
USB version	2.0
Standard interfaces	USB 2.0
Scan media weight	64 - 104.7 g/m²
Dimensions (WxDxH)	284 x 99 x 77 mm
Power requirements	AC 100 - 240V, 50/ 60 Hz
Non-operating relative humidity (non-condensing)	20 - 80 %
Minimum RAM	512 MB
Minimum storage drive space	2197 MB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	5 W
Power consumption (typical)	9 W
Operating temperature (T-T)	5 - 35 °C
Certification	RoHS

Weight and Dimensions

Depth	99 mm
Width	284 mm
Height	77 mm
Weight	1400 g
