Fujitsu ScanSnap S1300 User Manual

How to Perform a Scan (for Mac OS users)
173
■ Using the Quick Menu
The following explains the procedure for scanning by using the Quick Menu.
1. Check that the ScanSnap Manager icon is displayed in the Dock.
2. Select [Settings] from the ScanSnap Manager menu.
Refer to "ScanSnap Manager Menu" (page 170) for more information about the
ScanSnap Manager menu.
D The ScanSnap setup window appears.
3. Select the [Use Quick Menu] checkbox.
If the ScanSnap Manager icon is not displayed, from the Finder, select [Applications]
and double-click [ScanSnap] J [ScanSnap Manager] to start up ScanSnap Manager.
If the ScanSnap Manager does not appear in the Dock when Mac OS is started up, select
[Accounts] J [My Account] J [Login Items] J [+] J [ScanSnap Manager] in the [System
Preferences] window to add ScanSnap Manager.
For details about scanning documents without using the Quick Menu, refer to "Without
Using the Quick Menu" (page 177).

Fujitsu ScanSnap S1300 Specifications

General

Film scanning	No
Color scanning	Yes
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	10 sheets
USB version	2.0
Standard interfaces	USB 2.0
Scan media weight	64 - 104.7 g/m²
Dimensions (WxDxH)	284 x 99 x 77 mm
Power requirements	AC 100 - 240V, 50/ 60 Hz
Non-operating relative humidity (non-condensing)	20 - 80 %
Minimum RAM	512 MB
Minimum storage drive space	2197 MB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	5 W
Power consumption (typical)	9 W
Operating temperature (T-T)	5 - 35 °C
Certification	RoHS

Weight and Dimensions

Depth	99 mm
Width	284 mm
Height	77 mm
Weight	1400 g
