Fujitsu ScanSnap S1300 User Manual

ScanSnap Manager Icon and Operations (for Windows users)
42
■ Left-Click Menu
This menu appears when you click the ScanSnap Manager icon .
Currently saved profiles are displayed in a list.
You can switch to the previously saved scan settings by selecting a profile from the Left-Click
Menu.
If you are not using the Quick Menu, you can select a profile from the Left-Click Menu.
For details about how to save and manage profiles, refer to "Saving Scan Settings" (page 56).
z Clear the [Use Quick Menu] check box in the ScanSnap setup dialog box to display the Left-
Click Menu. The Left-Click Menu does not appear when this check box is selected.
z If you use ScanSnap S1300 on the same computer previously used with ScanSnap models
listed below, saved profiles are carried over:
- ScanSnap S1500/S1500M
- ScanSnap S510
- ScanSnap S500
- ScanSnap S300
Left-click
Left-Click Menu example

Fujitsu ScanSnap S1300 Specifications

General

Film scanning	No
Color scanning	Yes
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	10 sheets
USB version	2.0
Standard interfaces	USB 2.0
Scan media weight	64 - 104.7 g/m²
Dimensions (WxDxH)	284 x 99 x 77 mm
Power requirements	AC 100 - 240V, 50/ 60 Hz
Non-operating relative humidity (non-condensing)	20 - 80 %
Minimum RAM	512 MB
Minimum storage drive space	2197 MB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	5 W
Power consumption (typical)	9 W
Operating temperature (T-T)	5 - 35 °C
Certification	RoHS

Weight and Dimensions

Depth	99 mm
Width	284 mm
Height	77 mm
Weight	1400 g
