Basic Flow of Operations
31
Basic Flow of Operations
This section explains the flow of operations for scanning documents.
You can scan documents in two different ways. Choose either way depending on your
intended use.
z Using the Quick Menu
Select an action to be performed from the Quick Menu after scanning.
For Windows (J page 44)
For Mac(J page 173)
z Without Using the Quick Menu
Select a profile to be executed before scanning.
For Windows (J page 49)
For Mac (J page 177)
Specify whether or not to use the Quick Menu by selecting/clearing the [Use Quick Menu]
check box in the ScanSnap setup dialog box/window.
Open the ScanSnap setup dialog box/window by the following procedure:
Right-click the ScanSnap Manager icon or on the taskbar, and select [Scan Button
Settings].
In Windows 7, the ScanSnap Manager icon is displayed in the menu that appears when you
click in the taskbar.
Click the ScanSnap Manager icon or in the Dock while pressing the [control] key on
the keyboard, and select [Settings].

Fujitsu ScanSnap S1300 Specifications

General

Film scanning	No
Color scanning	Yes
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	10 sheets
USB version	2.0
Standard interfaces	USB 2.0
Scan media weight	64 - 104.7 g/m²
Dimensions (WxDxH)	284 x 99 x 77 mm
Power requirements	AC 100 - 240V, 50/ 60 Hz
Non-operating relative humidity (non-condensing)	20 - 80 %
Minimum RAM	512 MB
Minimum storage drive space	2197 MB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	5 W
Power consumption (typical)	9 W
Operating temperature (T-T)	5 - 35 °C
Certification	RoHS

Weight and Dimensions

Depth	99 mm
Width	284 mm
Height	77 mm
Weight	1400 g
