Fujitsu ScanSnap S1300 User Manual

Using the ScanSnap in Various Ways (for Mac OS users)
242
■ Scanning Color Documents in Black & White or Gray
Mode
By default, the ScanSnap automatically recognizes whether scanned documents are color,
gray or black & white, and outputs color documents in color mode, gray documents in gray
mode, and black & white documents in black & white mode.
If you want to scan color documents in gray or black & white mode, change the settings by
following the procedure below.
1. Select [Settings] from the ScanSnap Manager menu.
Refer to "ScanSnap Manager Menu" (page 170) for more information about the
ScanSnap Manager menu.
D The ScanSnap setup window appears.
2. From the [Color mode] pop-up menu in the [Scanning] tab, select [Gray]
or [B&W].
3. Click the [Apply] button in the ScanSnap setup window.
4. Click the [ ] button in the upper left corner or press the [esc] key to
close the ScanSnap setup window.

Fujitsu ScanSnap S1300 Specifications

General

Film scanning	No
Color scanning	Yes
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	10 sheets
USB version	2.0
Standard interfaces	USB 2.0
Scan media weight	64 - 104.7 g/m²
Dimensions (WxDxH)	284 x 99 x 77 mm
Power requirements	AC 100 - 240V, 50/ 60 Hz
Non-operating relative humidity (non-condensing)	20 - 80 %
Minimum RAM	512 MB
Minimum storage drive space	2197 MB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	5 W
Power consumption (typical)	9 W
Operating temperature (T-T)	5 - 35 °C
Certification	RoHS

Weight and Dimensions

Depth	99 mm
Width	284 mm
Height	77 mm
Weight	1400 g
