G1000 V8.XX S/W Load and Post Install Checkout – Columbia 350/400 Page 2-13
190-00577-04 Revision 1
2.7.1.1 ADF (if installed)
If the Columbia aircraft being updated is equipped with the Becker model RA3502 ADF (alternative
KR87), follow this procedure to configure the G1000. If the aircraft is not equipped with this option, this
procedure MUST be skipped.
1. At the System Upload page, activate cursor and rotate the FMS knob once to activate the
AIRFRAME menu.
2. Select ‘Options’ from the AIRFRAME window and press ENT.
3. From the FILE window, select ‘Columbia Option – Becker 3502 ADF’ or “Columbia Option –
KR87 ADF’ and press ENT.
4. Press the LOAD softkey.
5. Monitor the status of the upload. When the upload is finished, press ENT to acknowledge.
6. View the SUMMARY field and ensure that all items are ‘complete’: Verify that PASS appears in
green at the check box(es) as shown:
7. De-activate the cursor.
