Unit Installation
Installation Manual Pilot's Guide Appendix Index
1.1.5.6 PNEUMATIC HOSES AND CONNECTORS
Air hoses and fittings are required to connect pitot and static air to the G5. The
G5 has a female 1/8-27 ANPT fitting for each pitot and static port. Use appropriate
aircraft fittings to connect to pitot and static system lines.
1.1.5.7 SILICONE FUSION TAPE
Use Garmin Part Number 249-00114-00 or similar to wrap the wiring/cable bundles.
1.1.6 GARMIN SOFTWARE AND DOCUMENTS
The G5 unit software and a panel cut-out DXF file are available for free download
from www.garmin.com.
