190-02072-00 Rev. E
38
Unit Installation
Installation ManualPilot's GuideAppendixIndex
1.6 CONNECTOR INSTALLATION INSTRUCTIONS
1.6.1 SHIELD BLOCK INSTALLATION PARTS
Table 1-13 and Table 1-14 list the parts needed to install a Shield Block. The item
numbers in these tables correspond to the example drawing in Figure 1-22. The parts
listed in Table 1-13 are supplied in the G5 installation kit. The parts listed in Table 1-14
are to be provided by the installer as required.
Table 1-13 Garmin Supplied Shield Block Installation Parts for the G5
Item # Description GPN or MIL Spec
1 Backshell, Jackscrew, 9 pin 125-00171-00
6 Contact, Sckt, D-Sub, Crimp, Size 20, 20-24 AWG 336-00022-02
12 Clamp, Backshell, Jackscrew, 9 pin 115-01078-00
13 Screw, 4-40, 0.375” 211-60234-10
14 Cover, Backshell, Jackscrew, 9 pin 115-01079-00
15 Screw, 4-40, 0.187” 211-63234-06
