A.1.3 GPS DATA MESSAGE FORMAT
The GPS Data message is transmitted once per second.
Table A-2 GPS Data Message Format
Field Name Offset Width Units Notes Min Max
Escape character 0 1 '@'
UTC year 1 2 years
last two digits of UTC
year
00 99
UTC month 3 2 months 01 12
UTC day 5 2 days 01 31
UTC hour 7 2 hours 00 23
UTC minute 9 2 minutes 00 59
UTC second 11 2 seconds 00 59
Latitude
hemisphere
13 1
'N' = north
'S' = south
Latitude degrees 14 2 degrees 0 90
Latitude minutes 16 5
0.001
minutes
minutes x 1000 0 59999
Longitude
hemisphere
21 1
'E' = east
'W' = west
Longitude
degrees
22 3 degrees 0 180
Longitude
minutes
25 5
0.001
minutes
minutes x 1000 0 59999
