GE AF-650 GP Design And Installation Guide

13 Specifications
13.1 Power-dependent Specifications
13.1.1 Power, Currents and Enclosures
200–240 V
HP kW A Input Efficiency IP20/Chassis IP55/Type 12 IP66/Type 4X
0.37 0.25 1.8 1.6 0.94
12 15 15
0.5 0.37 2.4 2.2 0.94
1 0.75 4.6 5.9 0.96
2 1.5 7.5 6.8 0.96
3 2.2 10.6 9.5 0.96
5 3.7 16.7 15 0.96
7.5 5.5 24.2 22 0.96
23 21 21
10 7.5 30.8 28 0.96
15 11 46.2 42 0.96
24
22 22
20 15 59.4 54 0.96
31 3125 18 74.8 68 0.96
33
30 22 88 80 0.96
40 30 115 104 0.96
34 32 32
50 37 143 130 0.96
Table 13.1 200–240 V
380–480 V
HP kW
A Input Efficiency
IP00/Chassis IP20/Chassis IP21/Type 1 IP54/IP55/Type 12 IP66/Type 4X
≤ 440 V
>440 V
0.5 0.37 1.3 1.2 1.2 0.93
12
15 15
1 0.75 2.4 2.1 2.2 0.96
2 1.5 4.1 3.4 3.7 0.97
3 2.2 5.6 4.8 5 0.97
5 4.0 10 8.2 9 0.97
13
7.5 5.5 13 11 11.7 0.97
10 7.5 16 14.5 14.4 0.97
23 21 2115 11 24 21 22 0.98
20 15 32 27 29 0.98
25 18 37.5 34 34 0.98
24
22 22
30 22 44 40 40 0.98
40 30 61 52 55 0.98
31 3150 37 73 65 66 0.98
33
60 45 90 80 82 0.98
75 55 106 105 96 0.98
34 32 32
100 75 147 130 133 0.98
125 90 177 160 161 0.98
43
43h
41h/41 41h/41
150 110 212 190 204 0.98
200 132 260 240 251 0.98
44
41h/42 41h/42
250 160 315 302 304 0.98
44h 42h/42 42h/42
300 200 395 361 381 0.98
Specifications
AF-650 GP
TM
Design and Installation Guide
DET-767A 13-1
13 1
3

GE AF-650 GP Specifications
