GE AF-650 GP Design And Installation Guide

7.1.3 EMC Test Results (Emission)
The following test results were obtained using a system
with an adjustable frequency drive (with options, if
relevant), a shielded control cable, a control box with
potentiometer, as well as a motor and motor-shielded
cable.
RFI filter type Conducted emission.
Maximum shielded cable length.
Radiated emission
Industrial environment Housing, trades
and light
industries
Industrial
environment
Housing, trades and light
industries
Standard EN 55011
Class A2
EN 55011
Class A1
EN 55011
Class B
EN 55011
Class A1
EN 55011
Class B
Class A1/B RFI Filter installed
1–60 hp [0.75–45 kW] 200–240
V
500 ft [150 m] 500 ft [150 m] 164 ft [50 m] Yes No
1–125 hp [0.75–90 kW] 380–
480 V 500 ft [150 m] 500 ft [150 m] 164 ft [50 m] Yes No
Class A2 RFI Filter installed
1–5 hp [0.75–3.7 kW] 200–240
V
16.4 ft [5 m] No No No No
7.5–50 hp [5.5–37 kW] 200–240
V 82 ft [25 m] No No No No
1–10 hp [0.75–7.5 kW] 380–480
V
16.4 ft [5 m] No No No No
15–100 hp [11–75 kW] 380–
480 V 82 ft [25 m] No No No No
125–1,075 hp [90–800 kW]
380–480 V
500 ft [150 m] No No No No
125–1,600 hp [90–1,200 kW]
525–690 V
500 ft [150 m] No No No No
No RFI Filter installed
1–100 hp [0.75–75 kW] 525–
600 V - - - - -
Table 7.3 EMC Test Results (Emission)
7.2 Immunity Requirements
The immunity requirements for adjustable frequency drives
depend on the environment where they are installed. The
requirements for the industrial environment are higher
than the requirements for the home and office
environment. All GE adjustable frequency drives comply
with the requirements for the industrial environment and
consequently comply also with the lower requirements for
home and office environment with a large safety margin.
In order to document immunity against electrical
interference from electrical phenomena, the following
immunity tests have been made on a system consisting of
an adjustable frequency drive (with options if relevant), a
shielded control cable and a control box with potenti-
ometer, motor cable and motor.
The tests were performed in accordance with the following
basic standards:
•
EN 61000-4-2 (IEC 61000-4-2): Electrostatic
discharges (ESD): Simulation of electrostatic
discharges from human beings.
•
EN 61000-4-3 (IEC 61000-4-3): Incoming electro-
magnetic field radiation, amplitude modulated
simulation of the effects of radar and radio
communication equipment as well as mobile
communications equipment.
•
EN 61000-4-4 (IEC 61000-4-4): Electrical
interference: Simulation of interference brought
about by switching a contactor, relay or similar
devices.
Installation Consideration
AF-650 GP
TM
Design and Installation Guide
DET-767A 7-3
7
7
