GE AF-650 GP Design And Installation Guide

525–690 V
HP kW
HP
at
575
V
A Input Efficiency
IP00/Chassis IP20/Chassis IP21/Type 1 IP54/IP55/Type 12
≤ 550 V
>690 V
125 90 100 113 108 99 0.98
43 43h 41h/41 41h/41150 110 125 137 131 128 0.98
200 132 150 162 155 155 0.98
250 160 200 201 192 197 0.98
44 44h 42h/42 42h/42
300 200 250 253 275 240 0.98
350 250 300 303 290 296 0.98
450 315 350 360 344 352 0.98
550 355 400 395 380 366 0.98
52
51 51
600 400 400 429 410 395 0.98
650 500 500 523 500 482 0.98
750 560 600 596 570 549 0.98
900 630 650 639 630 613 0.98
61/63 61/631,000 710 750 763 730 711 0.98
1150 800 950 889 850 828 0.98
1250 900 1050 988 945 920 0.98
62/64 62/64
1350 1,00
0
1150 1108 1060
1032 0.98
1600 1200 1350 1317 1260 1260 0.98
Table 13.4 525–690 V
13.1.2 Dimensions, Unit Size 1x
Figure 13.1 Unit Size 12
Specifications
AF-650 GP
TM
Design and Installation Guide
DET-767A 13-3
13 1
3

GE AF-650 GP Specifications
