Appendix B: Reference tables
130 Concord 4 Installation Manual
System event triggers
Table 26 below describes the system event triggers.
Table 26: System event trigger
System event Description
Trigger
number
Null trigger (used for direct control) Activates only by schedule or direct command. 000
Fire alarm When fire sirens are started. 001
Police alarm When police sirens are started. 002
Auxiliary alarm When auxiliary sirens are started. 003
Any audible alarm When any of the above sirens are started. 004
Silent alarm (sensor groups 2, 3, and
duress)
When a group 2 or 3 sensor goes into alarm or
when a duress alarm is activated (does not
include groups 25, 27, 28, or 32).
005
Any audible or silent alarm When any alarm is started (does not include
groups 25, 27, 28, or 32).
006
HOM group 27, 28, 32 in alarm When a sensor in group 27, 28, or 32 goes into
alarm.
007
Major trouble (phone or receiver
failure)
When a receiver failure (S94) or a phone failure
(S96) occurs.
008
Arming to stay or away When the system is armed to level 2 or 3. 009
Arming to away When the system is armed to level 3. 010
AVM is interactive (audio session in
progress)
When the central station operator begins
listening or talking to the premises.
011
Fail-to-communicate (panel can’t
call CS or pager)
When the fail-to-communicate output is
activated.
012
AVM trip (edge) When an AVM alarm occurs, output is activated
momentarily.
013
Keychain touchpad star button-
press
When the star button on a keychain touchpad is
pressed.
014
Smoke power (for resetting four-wire
smoke detectors)
Deactivated when hardwire smoke detectors
need to be reset.
015
Exterior siren Activated for police or fire alarms. 016
Interior siren Activation follows all system noises 017
AVM trip (pulse) When an AVM alarm occurs, output is
deactivated for 10 ms
018
State of system status Follows the state of system status (ready or
trouble).
019
Tamper condition When any tamper is tripped 020
