Chapter 3: Programming
Concord 4 Installation Manual 57
Light control menu
The Light control menu lets you set up light activation for a specific partition.
Note: For light control to work you must power the panel with a power line carrier
transformer and X10 powerhouse lamp modules must be installed at desired lamps.
Light control - partition 1 to 6 settings
Entry lights
Shortcut: 0400 to 0450
Default: None
This setting determines which X10 controlled lights turn on during entry
and exit delays.
The X10 lamp modules set to 1 always turn on during the entry and exit
delays. X10 lamp modules set to 2 always flash the arming level when
arming the system. For example, lights flash two times when arming to
stay (Level 2), and three times when arming to away (Level 3).
To set the entry lights:
1. With the desired partition selected, press #. The display shows
NTRY
LIGHTS nnnnnnn (current setting).
2. Enter all the desired light numbers (3 to 9) based on the unit dial
setting on each X10 lamp module.
3. The display flashes the entered settings. Press # and the display
shows the new settings.
To delete entry lights, enter any light number that appears on the
display, then press #. The number disappears from the display.
House code
Shortcut: 0401 to 0451
Default: 01 B, 02 C, 03 D,
04 E, 05 F, and 06 G
This setting enables X10 controlled lights to work in a selected partition
without interfering with the X10 controlled lights of the other partitions.
After setting the panel house code for each partition, you must set the
X10 controlled lights for that partition to the same house code. The
letter that appears automatically after the house code number
indicates the necessary house dial setting for X10 modules in that
partition (1 to 255).
