Chapter 3: Programming
Concord 4 Installation Manual 89
System version menu
The System version menu lets you view and identify panel hardware and software.
This information is primarily used for troubleshooting purposes.
System version
Shortcut:
010 (factory code),
011 (system number),
012 (system level),
013 (software version)
This menu lets you view and identify panel hardware and software
version.
To view and identify the system version:
1. Press A or B until the display shows SYSTEM VERSION.
2. Press # and the display shows FACTORY CODE nnn*nnnn.
3. Press B and the display shows SYSTEM NUMBER *nnnnnnn.
4. Press B again and the display shows SYSTEM LEVEL nnnn.
5. Press B again and the display shows SW VERSION nnnnx (panel
firmware version).
Downloader programming
The panel can be programmed remotely using Enterprise Downloader. Use the
information you recorded in Appendix A “System planning sheets” on page 111 to
inform the downloading operator of the programming requirements for this system.
A Downloader phone number should be programmed and the user-programmable
option Downloading must be powered on for remote downloader programming to
work.
To initiate an Enterprise Download session:
1. Contact your download station and ask the operator to prepare to download to
the panel.
2. Make sure the system is disarmed.
3. Press 8, system master code, 7, 0 (any), 1 (down) or 2 (up). The display shows
SYSTEM DOWNLOAD IN PROGRESS during the downloading process.
If the alphanumeric touchpad does not display SYSTEM DOWNLOAD IN
PROGRESS, call the downloader operator to verify the downloader phone number.
Also, make sure Enterprise ToolBox is set up properly.
