2018112-003 Rev J eBike, eBike L, eBike EL - 71 -
F: Servicing Instructions
Part F: Servicing Instructions
F-1. Spare Parts for Repair of eBike
Overview: Adjustments required after replacement of assemblies
Replaced Assembly Required Adjustment
chassis no replacement
drive unit with PCB RPM no adjustment required
PCB RPM requires calibration (8 kg)
steel wire on drive unit requires calibration (8 kg)
PCB Interface (= PCBIF) check DIP switches + menu settings (e.g. EKG type)
control terminal check contrast of LCD display
PCB Display in control terminal no adjustment required
power supply no adjustment required
PCB BP in control terminal no adjustment required
NIBP pump module in base assembly no adjustment required
saddle tube calibration of saddle height indication
saddle motor (eBike Comfort only) calibration of saddle height indication
saddle height indication (eBike Basic / no adjustment required
eBike Comfort only)
clamping lever grease clamping lever
software update check settings and EKG type in particular
only eBike L / eBike EL:
saddle motor no adjustment required
lift motor for supine plane position perform reset
lift motor for leftside slope position perform reset
motor control perform reset
remote control no adjustment required
