GE eBike Service Manual

- 72 - eBike, eBike L, eBike EL 2018112-003 Rev J
F: Servicing Instructions
F-2. Spare Parts for Repair of eBike L / eBike EL
Overview: Adjustments required after replacement of assemblies
Replaced Required Required
Assembly Adjustment Procedures
chassis no replacement
drive unit with PCB RPM no adjustment required removing casing
PCB RPM requires calibration (8 kg) remove casing
steel wire on drive unit requires calibration (8 kg) remove casing
PCB Interface (= PCBIF) check DIP switch + check menu
settings (e.g. EKG Type)
control terminal no adjustment required check contrast
PCB Display in control terminal no adjustment required check contrast
power supply no adjustment required
PCB BP in control terminal no adjustment required
NIBP pump module in connection box no adjustment required
saddle motor no adjustment required
lift motors reset motor control
motor control reset motor control
remote control no adjustment required
clamping lever grease clamping lever
software update check settings and EKG Type,
in particular
