Chapter 3: Programming
EST iO64 and iO500 Technical Reference Manual 115
Loop configuration options
The loop configuration options are the loop class, zone, device,
mapping, and correlation groups. Each option has settings that can
be programmed. Most options also have a factory default setting,
which can be used with no additional programming. See "Factory
Default Settings" for more information.
Reports
Test
Control
Program
⇩
Program
Incremental Program
Auto Program
Advanced Program
⇩
Enter Password
0000
⇩
To access the loop configuration options:
1. Press the Menu button.
2. Choose Program.
3. Choose Advanced Program.
4. Enter the level two password.
5. Choose Loop Configuration.
6. Program the options.
Advanced Program
Loop Configuration
Panel Configuration
Panel Operation
