Chapter 2: Installation and wiring
EST iO64 and iO500 Technical Reference Manual 59
Panel low voltage wiring
Circuit specifications
• Circuit voltage: 24 VAC
Panel low voltage wiring
TB1
EGND
24 VAC
IN
Terminal wiring location
