Technical Specifications
Table 53: Display Specifications
Item Description
Display 39.6 cm (15.6 in) diagonal graphics LED backlit full HD
Touchscreen Projected Capacitative (PCAP) multipoint touch input that works
while wearing medical exam gloves
Resolution 1920 X 1080 pixels, with waveform enhancement
Data Heart rate, patient name, patient ID, date and time, battery power
indicator, scrolling waveforms, lead labels, speed, gain and filter
settings, warning messages, prompts, hookup advisor, and help
messages.
Sensors Accelerometer for putting unit in standby when display is closed
Table 54: Keypad Specifications
Item Description
Type Sealed elastomer membrane keyboard with tactile feedback
Keys Function keys
Alphanumeric keys
Writer controls
Trimpad cursor controls
Keypad Keypad and lettering are water and chemical resistant tested in
accordance with ASTM D 543.
Table 55: Printer Specifications
Item Description
Technology Integrated thermal dot array
Writer speed 5, 12.5, 25, and 50 mm/s
Number of traces 3, 6, 12, or 15 (user-selectable)
Sensitivity/gain 2.5, 5, 10, 20 mm/mV, and 10/5 mm/mV split gain
Speed accuracy 5, 12.5 mm/s at ±5%
25, 50 mm/s at ±2%
Amplitude accuracy ±5%
Horizontal resolution 40 dots/mm at 25 mm/s
Vertical resolution 8 dots/mm
Paper type Z-fold thermal with pre-printed grid and perforation
2088531-370-2 MAC VU360
™
Resting ECG Analysis System 161
