Chapter 2. Installation
Moisture Target Series 6 Hygrometer User’s Manual 11
2.3.1 Basic Mounting (cont.)
6. Use a screwdriver to extend the bracket screws to the back of the panel
and secure the MTS6 in the panel cutout (see Figure 14).
Figure 14: Securing the MTS6 to the Panel
7. Using a feeler gauge behind the gasket, check the compression, and
tighten the bracket screws until the gap is 0.028” ±0.002” (see
Figure 15).
Figure 15: Checking the Gasket Compression
