GE T1000 User Manual

GE Reason Switches
Chapter 7 – Configuration
200
REASON SWITCHES-TM-EN-3
 Save: save configuration at the Running Config;
 Reset: undo changes made locally at the
Running Config;
 Cancel: cancel changes made locally and return
to previous page.
11.7 Port DSCP
Port DSCP menu allows enabling DSCP QoS function and basic configuration. At this
menu it is possible to enable if DSCP will be used as quality of service mechanism
and define basic behaviour of its usage. Possible configurations are as follows.
o Port: shows the port to be configured at this row;
o Translate: indicates if ingress translation should be used by this
port. This checkbox is used together with the Classify field to define
the ingress rules of the DSCP function. Checkbox selected means
ingress translation enabled, and checkbox empty means disabled;
o Classify: indicates how should be executed DSCP ingress
classification. Possible configuration is as follows:
 Disable: indicates that no ingress DSCP is used. This
means that DSCP analysis for QoS function is disabled at
the port;
 DSCP=0: indicates that only frames with DSCP bits equal 0
should be classified. DSCP-to-QoS Class classification will
be as configured at the DSCP Classification;
 Selected: indicates that only frames with DSCP bits
marked should be classified. If selected, the DSCP
Translation menu should be used to select which DSCP
levels should be classified;
 All: indicates that all frames with DSCP bits will be
classified. If selected, all frames will be classified to a
DSCP queue.
o Egress: indicates how should be executed DSCP egress rewriting
process. Possible configuration is as follows:
 Disable: indicates that no egress DSCP rewriting is used.
This means that DSCP bits of a given incoming frame will
be discarded at the egress process;
 Enable: indicates that egress DSCP rewriting is used, but
there is no remap of the DSCP bits. This means that DSCP
bits of a given incoming frame will be maintained at the
egress process;
