2 Ports
This menu provides online monitoring regarding the State, Traffic Overview, QoS
Statistics, QCL Status and Detailed Statistics of each port.
If desired to update Reason Switches web screen automatically, check the Auto
Refresh checkbox on top to perform it. If selected, monitoring web page will be
updated after 3 seconds of the last update automatically.
State:
State option allows user to view basic information about each port state in Reason
Switches. A picture representing the switch with all interface ports is shown on the
screen. Each port type possible is represented in a picture, that is, the pictures show if
port type is ST connector, LC connector or RJ45 connector, as follows:
o RJ45 connector representation at the web
interface;
o SFP connector representation at the web
interface;
o ST connector representation at the web interface.
The ST connector port is only allowed in T1000 Switches. The S2020 and S2024G switches use only RJ45 and LC connectors.
In addition port state is displayed:
o Port disabled;
o Port enabled and up, that is, with link connected and
communicating;
o Port enabled and down, that is, without link connected or
communicating;
Traffic Overview:
Traffic Overview option allows user to view basic information about data traffic in
Reason Switches. It is shown in the screen a table which contains the following
information:
