9 VLAN
This section presents the VLAN table and ports for monitoring purposes, providing
information about the VLANs Membership and Ports menu.
If desired to update Reason Switches web screen automatically, check the Auto
Refresh checkbox on top to perform it. If selected, monitoring web page will be
updated after 3 seconds of the last update automatically.
VLAN Membership:
VLAN Membership Status for Combined users table allows monitoring current VLANs
configured and running at the switch.
o VLAN ID;
o Port members, divided in checkboxes per port.
Symbol shown at a port column means that the port
is a member of VLAN ID related to the row;
Symbol shown at a port column means that the port
is not a member of VLAN ID related to the row.
VLAN Ports:
VLAN Ports Status for Combined users table allows monitoring current port VLAN
information configured and running at the switch.
o Port number;
o Port type, that is, if port is Unaware, C-Port, S-Port, S-Custom-Port;
o Ingress filtering at the port. Checkbox enabled means port is
performing port filtering, and checkbox disabled means port is not
performing port filtering;
o Frame type. If ingress filtering is enabled, frame type column will
display which frame types are allowed at that port. Possible values
are All, Tagged or Untagged;
o Port VLAN ID;
o Port Tx Tag, that is, configured transmission tag behavior. Possible
values are Untag All, Tag All and Untag PVID;
o Untagged VLAN ID, which indicates frame behavior at the egress
process;
o VLAN Conflicts status. Conflicts can be functional conflicts or
hardware limitation (conflict between user modules).
