18 ADL500 • Quick installation guide - Specifications and connection
5 - Options
5.1 External fuses
5.1.1 Network side fuses (F1)
The inverter must be fused upstream on the network side.
Use fast-acting fuses only.
Size
F1 - External network side fuses
DC link capacitor hours of
service life [h]
EUROPE AMERICA
Type Code Type Code
ADL5...-...-4, 3ph
1040 > 15000 GRD2/20 F4D15 A70P20 S7G48
1055 > 15000 GRD2/25 F4D16 A70P25 S7G51
1075 > 15000 GRD3/35 F4D20 A70P40 S7G52
2110 > 15000 Z22GR40 F4M16 A70P40 S7G52
2150 > 15000 Z22GR63 F4M17 A70P60-4 S7I34
Technical data for fuses, including dimensions, weights, power leakage, fuse carriers etc. are reported in the corresponding manufacturers' data sheets:
GRD... (E27), S00... = Jean Müller, Eltville; A70...= Ferraz.
5.2 Input chokes
The three-phase mains choke is strongly recommended in order to:
- limit the RMS input current of the ADL500 inverter.
- increase the life of intermediate circuit capacitors and reliability of input diodes.
- reduce mains harmonic content
5.2.1 AC input chokes
Size
Effective input current In
(@400V/50Hz, with AC input chokes)
(A)
Model Code
Dimensions:
Width x Height x Depth
mm [inches]
Weight
kg [lbs]
ADL5...-...-4, 3ph
1040 9 LR3y-2040 S7AAG 120 x 125 x 65 [4.7 x 4.9 x 2.6] 2 [4.4]
1055 13.5 LR3y-2055 S7AB5 120 x 125 x 75 [4.7 x 4.9 x 2.6] 2.2 [4.4]
1075 18 LR3y-2075 S7AB6 150 x 155 x 79 [5.9 x 6.1 x 3.1] 4.9 [10.8]
2110 24 LR3y-3110 S7AB7 150 x 155 x 79 [5.9 x 6.1 x 3.1] 5 [11]
2150 32 LR3y-3150 S7AB8 150 x 169 x 85 [5.9 x 6.7 x 3.3] 5.5 [12.1]
5.2.2 DC input chokes
Size
Effective input current I
n
(with external DC chokes)
External DC chokes
@230V/50Hz @400V/50Hz @480V/50Hz
Rated
current
Overload
current
Model Code
Dimensions:
Width x Height x Depth
Weight
(A) (A) (A) (Arms) (*) (Arms) mm [inches] kg [lbs]
ADL5...-...-4, 3ph
1040 8 8 7.5 10 20 LDC-004 S7AI10 99 x 96 x 93 [3.90 x 3.78 x 3.66] 2.4 [5.3]
1055 12 12 11 16 31 LDC-005 S7AI11 125 x 112 x 98 [4.92 x 4.41 x 3.86] 4.1 [9.0]
1075 16 16 14 21 41 LDC-007 S7AI12 125 x 127 x 122 [4.92 x 5.00 x 4.80] 4.9 [10.8]
2110 21 21 18 28 54 LDC-011 S7AI13 125 x 127 x 142 [4.92 x 5.00 x 5.59] 6.6 [14.6]
2150 28 28 25.5 36 70 LDC-015 S7AI14 125 x 127 x 152 [4.92 x 5.00 x 5.98] 8 [17.6]
(*) 10s every 60s.
