ADV200 • Functions description and parameters list 143
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.2.5 4012Fieldbusalarmmode INT32 0 0 1 ERWZ FVS
Setting of the OptBusFault alarm generation mode.
0 Off
1 On
If set to0 the alarm is only generated if the drive is enabled.
If set to 1 the alarm is generated even with the drive disabled.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.2.6 4014Fieldbusstate ENUM Stop 0 9 R FVS
The logic status of the eldbus connection is displayed. The value depends on the type of bus that is used.
The following logic states are displayed if the CANopen or Rte eldbus is selected:
0 Stop
1 PreOperational
2 Operational
The following logic states are displayed if the Probus eldbus is selected:
3 Error
4 WaitPRM
5 WaitCFG
6 DataExchange
7 DPError
The following logic states are displayed if the Rte eldbus is selected:
8 SafeOp
9 Init
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.2.7 4398RTEprotocol ENUM None 0 6 ER FVS
The Real Time Ethernet protocol implemented on the expansion card is displayed.
0 None
1 Ethercat
2 EthernetIP
3 GdNet
4 Pronet
5 ModbusTCP
6 Powerlink
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.2.8 5608IPaddress UINT32 0 0 4294967295 ER FVS
Display of DCP address set via conguration of Pronet node.
23.3–COMMUNICATION/FIELDBUSM2S
Congurationofinputdata
There are 16 groups of parameters, with the same structure, for conguring data to be exchanged cyclically with the
eldbus. Each group permits the exchange of a single datum, which corresponds to a single drive parameter.
The data written by the Master (a PLC, PC or control panel) to the Slave (the drive) can be congured in the COMMU-
NICATION/FIELDBUS M2S menu, hence the name of the M->S menu:
Parameterforsettinginputdata:
It must contain a valid IPA corresponding to the parameter to be written, or 0 if sys (PAR 4022...4172 FieldbusM->Sn
sys) is Fillor Mdplc.
