192 ADV200 • Messages
D–MESSAGES
Note ! For more information see Quick start guide, chapter6.7.
Index Errormessageshown
onthedisplay
Sub-code Description
1 Loaddefaultparam
Condition:may occur during loading of the parameter database saved in flash
normally appears in the following conditions: at initial power-on when a new firmware version is downloaded, when
the regulation is installed on a new size, when the region is changed.
If this message is displayed when the drive is already operating, this means that a problem has occurred in the param-
eter database saved in Flash.
If this message is displayed the drive restores the default database, i.e. the one downloaded.
0001H-1 The database saved is not valid
0002H-2 The database saved is not compatible
0003H-3 The database saved refers to a different size from the current size
0004H-4 The database saved refers to a different region from the current region
Solution:Set the parameters to the value required and perform Saveparameter
2
3
4
Optiondetectslot1
Optiondetectslot2
Optiondetectslot3
Condition: at power-on, the drive recognizes the presence of an optional card in one of the three expansion slots.
One of the three messages is shown on the display
0H-0 None
0004H-4 Can/DeviceNet
00FFH-255 Unknown
0104H-260 Profibus
0204H-516 Rte
0208H-520 Enc 3 EXP-SESC- I1R1F2-ADV
0301H-769 I_O_1
0308H-776 Enc 4 EXP-EN/SSI- I1R1F2-ADV
0408H-1032 Enc 5 EXP-HIP- I1R1F2-ADV
0608H-1544 Enc 1 EXP-DE-I1R1F2-ADV
0701H-1793 I_O_2
0108H-1800 Enc 2 EXP-SE-I1R1F2-ADV
0808H-2056 Enc 7 EXP-DE-I2R1F2-ADV
0901H-2305 I_O_3
0D01H-3329 I_O_4
0508H-1288 Enc 6 EXP-RES-I1R1-ADV
908H-2312 Enc 8 EXP-ASC-I1-ADV
Solution:
5 Autotune Condition:this may occur during the Autotune procedure
0 No error
1
The commands are not configured in Local mode.
Solution: Execute the requested configuration
2
The Commands local sel parameter has not been configured from the keypad
Solution: Execute the requested configuration
3
The motor plate data parameters have changed but the Takeparameterscommand, PAR 2020,
has not been executed
Solution: Execute the Takeparameters command.
4
Error in motor connection.
Solution:Check the motor connection, set the value of the direct current of the motor to 1/3 and
perform the motor autotune procedure. Then increase the direct current until autotuning is execut-
ed. The penultimate value is the nominal current value at which the drive performs autotuning.
5
While running self-tuning the ESC key was pressed or the enable contact was opened or an alarm
occurred. The Autotunecommand was sent with the drive in the alarm condition
Solution: Eliminate the reason for the alarm, remove the reason for the opening of the enable
contact, reset alarms.
6
A setting performed by the Autotune function produced a parameter value outside the min or max
range.
Solution: Check the motor plate data or drive and motor sizes have been combined incorrectly.
7
The Autotunecommand was sent without being enabled.
Solution: Close the enable contact before sending the Autotune command
