152 ADV200 • Functions description and parameters list
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.6.2 4452Worddecompsrc LINK 16 4450 0 16384 ERW FVS
Selection of the origin (source) of the word to be decoded by the “Worddecomp” block. Each bit that is part of
the word to be decoded is associated with the output channel of the “Worddecomp” block. The variables that
can be used for this function can be selected from among those listed in the “L_WDECOMP” selection list.
Word decomp src
Bit0 decomp mon
WORD_0
BIT_0
BIT_1
BIT_14
BIT_15
BIT_1
......... ................
Bit10 decomp mon
Bit14 decomp mon
Bit15 decomp mon
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.6.3 4454Bit0decompmon BIT 16 0 0 1 ER FVS
23.6.4 4456Bit1decompmon BIT 16 0 0 1 ER FVS
23.6.5 4458Bit2decompmon BIT 16 0 0 1 ER FVS
23.6.6 4460Bit3decompmon BIT 16 0 0 1 ER FVS
23.6.7 4462Bit4decompmon BIT 16 0 0 1 ER FVS
23.6.8 4464Bit5decompmon BIT 16 0 0 1 ER FVS
23.6.9 4466Bit6decompmon BIT 16 0 0 1 ER FVS
23.6.10 4468Bit7decompmon BIT 16 0 0 1 ER FVS
23.6.11 4470Bit8decompmon BIT 16 0 0 1 ER FVS
23.6.12 4472Bit9decompmon BIT 16 0 0 1 ER FVS
23.6.13 4474Bit10decompmon BIT 16 0 0 1 ER FVS
23.6.14 4476Bit11decompmon BIT 16 0 0 1 ER FVS
23.6.15 4478Bit12decompmon BIT 16 0 0 1 ER FVS
23.6.16 4480Bit13decompmon BIT 16 0 0 1 ER FVS
23.6.17 4482Bit14decompmon BIT 16 0 0 1 ER FVS
23.6.18 4484Bit15decompmon BIT 16 0 0 1 ER FVS
The single bits that make up the selected word are displayed.
23.7-COMMUNICATION/EXTERNALIO
The optional EXP-FL-XCAN-ADV card (generally inserted in slot 1) allows the number of I/Os managed by the
drive to be increased, using an external device. Communication with the external device is performed via CAN
using the “DS401 Device prole for generic IO modules”.
For more details see manual 1S5F32_EXP-FL-XCAN-ADV.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.7.1 5480ExternalIOenable ENUM Disable 0 1 ERW FVS
This parameter is used to enable or disable communication between the EXP-FL-XCAN-ADV card and the
external device.
0 Disable
1 Enable
Communication is disabled in the default conguration. Communication can be enabled by setting Enable and
saving the parameters. When the drive is re-started the EXP-FL-XCAN-ADV card, if installed, is recognised.
