819XX_MAN_GRM-H_11-2022_ENG_pag. 30
5.1.2.4. Current reading scale maximum limit
Acronym App / GF_eXpress menu Attribute Retentive U.M. Default
Description
H.tA
Inputs  CT input
R
■
A
(*)
Current reading scale maximum limit.
(*)
5.1.2.5. Real-time current reading input value
Acronym App / GF_eXpress menu Attribute Retentive U.M. Default
Description
I.tA
Expert  Status  Current
R - A -
Current reading real-time value.
5.1.2.6. Current reading input value
Acronym App / GF_eXpress menu Attribute Retentive U.M. Default
Description
I.onF
Expert  Status  Current
R - A -
Filtered current reading value, at active power output
(SSR operating phase).
5.1.2.7. Current reading status
Acronym App / GF_eXpress menu Attribute Retentive U.M. Default
Description
STATUS3
Expert  Status  Diagnostics
R - - -
Current reading self-diagnosis status.
Model Default
15 A 25.0
25 A 25I A 40.0
30 A 30I A 50.0
40 A 60.0
50 A 80.0
60 A 100.0
75 A 120.0
90 A 150.0
120 A 200.0
bit Meaning
13 Broken current sensor
