819XX_MAN_GRM-H_11-2022_ENG_pag. 92
GRM-H
GRM-H
GRM-H
GRM-H
GRM-H
GRM-H
GRM-H
GRM-H
GRM-H
Rated current curves as a function of the horizontal distance between the GRM-Hs (ambient temperature 40
C / 104
F).
N.B: The curves of the GRM-H 90/120 refer to the device complete with a working specified fan.
DERA
TING CURVES GRM-H 75 ÷ 120A
DERA
TING CURVES GRM-H 40 ÷ 60A
DERA
TING CURVES GRM-H 15 ÷ 30A
7.3.
Downgrade with installation distance
91
93
