5.2.4.3. Pin 13 input/output type
Acronym App / GF_eXpress menu Attribute Retentive U.M. Default
Description
io.13.t
Inputs/Outputs R/W
■
0
Pin 13 input/output type (for GRM-H-x-x-AN-x-x-x-x-x-x-x models only).
Options:
5.2.4.4. Function for pin14 input
Acronym App / GF_eXpress menu Attribute Retentive U.M. Default
Description
i.14
Inputs/Outputs R/W
■
0
Function for input relative to pin14 (for GRM-H-x-x-I-x-x-x-x-x-x-x models only).
Options:
5.2.4.5. Pin 14 input type
Acronym App / GF_eXpress menu Attribute Retentive U.M. Default
Description
i.14.t
Inputs/Outputs R/W
■
0
Tipologia dell’ingresso pin 14 (solo per modelli GRM-H-x-x-I-x-x-x-x-x-x-x).
Options:
0 Direct (if output, normally off)
1 Reverse (if output, normally on)
Value Function Notes
0 Digital input off
1 HB calibration Rising edge
2 Feedback calibration Rising edge
3 Software OFF In=1: Software Off ,
In=0: Software On
4 HB and PF alarm memory reset In=1: Alarms reset,
In=0: Normal alarm status
5 Dryout restart Rising edge
6 Dryout end Rising edge
0 Direct
1 Reverse
