5.2.4.6. Function for pin17 input/output
Acronym App / GF_eXpress menu Attribute Retentive U.M. Default
Description
io.17
Inputs/Outputs R/W
■
48
Function for input or reference for output relative to pin17.
Options:
5.2.4.7. Pin 17 input/output type
Acronym App / GF_eXpress menu Attribute Retentive U.M. Default
Description
io.17.t
Inputs/Outputs R/W
■
0
Pin 17 input/output type.
Options:
Value Function Notes
0 I/O disabled
1 In - HB calibration Rising edge
2 In – Feedback Calibration Rising edge
3 In – Software OFF In=1: Software Off ,
In=0: Software On
4 IN - HB and PF alarm memory reset In=1: Alarms reset,
In=0: Normal alarm status
5 In – Dryout restart Rising edge
6 In – Dryout end Rising edge
14 In – MAN/AUTO control In=1: MAN, In=0: Auto
15 In – SSR Main In=1: SSR ON, In=0: SSR OFF
32 Out – HB or PF alarms
33 Out – HB alarm
34 Out – PF alarms
35 Out - SSR overtemperature
36 Out – HB or PF alarms or SSR
overtemperature
37 Out – HB alarm or SSR overtemperature
38 Out – PF alarms or SSR overtemperature
39 Out – Dryout status
40 Out – Communication error
48 Out – Master/Slave output Signal retransmission for 2PH and 3PH to
other SSRs
0 Direct (if output, normally off)
1 Reverse (if output, normally on)
