5.2.4.8. Function for pin19 output
Acronym App / GF_eXpress menu Attribute Retentive U.M. Default
Description
o.19
Inputs/Outputs R/W
■
36
Reference for output relative to pin19.
Options:
5.2.4.9. Pin 19 output type
Acronym App / GF_eXpress menu Attribute Retentive U.M. Default
Description
o.19.t
Inputs/Outputs R/W
■
0
Pin 19 output type.
Options:
5.2.4.10. PWM input timeout
Acronym App / GF_eXpress menu Attribute Retentive U.M. Default
Description
PWM.t
Inputs/Outputs R/W
■
s 1.00
The parameter sets the timeout time relative to the digital input configured with PWM function.
NOTE:
If the digital input is used to control the power % (Ou.P) to be delivered on the load (PWM input
function), it is important to set the Timeout parameter PWm.t to a value equal to or greater than the
period of the PWM control signal used, in order to guarantee a reaction time even in static conditions
of low (Ou.P = 0%) or high (Ou.P = 100%) input.
min...max: 0.01 ...10.00 s
Value Function
0 Output disabled
32 HB or PF alarms
33 HB alarm
34 PF alarms
35 SSR overtemperature
36 HB or PF alarms or SSR overtemperature
37 HB alarm or SSR overtemperature
38 PF alarms or SSR overtemperature
39 Dryout status
40 Communication error
0 Direct (normally off)
1 Reverse (normally on)
