7.4. Extrarapid fuses
7.5. Accessoires
7.6. Fans (for 90A/120A models only)
An electrical protection device known as a GG FUSE must be used to ensure protection against short-circuit of the electrical cable (see EN 60439-1,
paragraph 7.5 Short-circuit protection and short-circuit withstand strength” and 7.6 “Switching devices and components installed in ASSEMBLIES”,
or the equivalent paragraphs of standard EN 61439-1).
Code Description
F089025 1 NFC dongle for configuration via App + 1 Gefran keychain lanyard
F089026 5 NFC dongles for configuration via App + 5 Gefran keychain lanyards
F089027 10 NFC dongles for configuration via App
F060800 Cable for programming with PC, USB-TTL 3 V with USB - microUSB connectors, length 1,8 m
Model Fuse manufacturer Fuse Model size
GRM-H 15 Bussmann Div Cooper (UK) Ltd FWC16A10F 10x38
GRM-H 25/25I Bussmann Div Cooper (UK) Ltd FWC25A10F 10x38
GRM-H 30/30I Bussmann Div Cooper (UK) Ltd FWP40A14F 14x51
GRM-H 40 Bussmann Div Cooper (UK) Ltd FWP40A14F 14x51
GRM-H 50 Bussmann Div Cooper (UK) Ltd FWP63A22F 22x58
GRM-H 60, GRM-H 75 Bussmann Div Cooper (UK) Ltd FWP80A22F 22x58
GRM-H 90 Bussmann Div Cooper (UK) Ltd FWP100A22F 22x58
GRM-H 120 Bussmann International Inc. USA 170M1418 000-TN/80
Model Code Type Supply
90A FAN60 363484
230 Vac 60mm x 60mm x 30mm for 90A models Separate power supply
120A FAN60 363011
230Vac 80mm x 80mm x 38 mm for 120A models Separate power supply
90A FAN61 363485
115Vac 60mm x 60mm x 30 mm for 90A models Separate power supply
120A FAN61 363003
115Vac 80mm x 80mm x 38 mm for 120A models Separate power supply
FAN62 363037
24 Vdc 60mm x 60mm x 25mm Separate power supply
FAN63 363037
24 Vdc 60mm x 60mm x 25mm Internally powered by GRM-H
PERIODIC CLEANING
Every 6-12 months (depending on dust in the place where it is installed), blow a jet of compressed air downward through the cooling heatsink
(on the opposite side of the fan).
In this way both the heat sink and the cooling fan are cleaned.
IN THE EVENT OF OVERTEMPERATURE ALARM
If periodic cleaning does not eliminate the problem, perform the following operations:
1. Disconnect the fan cables from the terminal block (if present) or disconnect the fan connector from the GRM-H (FAN63).
2. Unscrew the screws securing the fan to the support brackets
3. Check the condition of the fan, clean it or replace it
4. Reassemble the fan
