Super Match
2.Indoor unit dip switch setting and function
AD09~24SS1ERA(N)(P) AD12MS1ERA AD18MS1ERA AD24MS2ERA
SW1-1 SW1-2 SW1-3 SW1-4 SW1-5 SW1-6 SW1-7 SW1-8 Description
1 0 0 --- --- --- --- --- 09K indoor unit
0 1 0 --- --- --- --- --- 12K indoor unit
0 0 1 --- --- --- --- --- 18K indoor unit
1 0 1 --- --- --- --- --- 24K indoor unit
0 1 1 --- --- --- --- --- 28K indoor unit
--- --- --- 0 0 --- --- --- Static pressure: 1st
--- --- --- 0 1 --- --- --- Static pressure: 2nd
--- --- --- 1 0 --- --- --- Static pressure: 3rd
--- --- --- 1 1 --- --- --- Static pressure: 4th
--- --- --- --- --- 1 --- --- Room card valid
--- --- --- --- --- 0 --- --- Room card invalid
--- --- --- --- --- --- 0 0 Slim duct
（
AD**SS1ERA)
--- --- --- --- --- --- 1 0 Med ESP duct(AD*MS2ERA)
2.1 Indoor unit dip switch setting
AB24ES1ERA(S) (1
：
ON 0
：
OFF)
SW1-1 SW1-2 SW1-3 SW1-4 SW1-5 SW1-6 SW1-7 SW1-8 Description
1 0 1 --- --- --- --- --- 24K indoor unit
--- --- --- 0 --- --- --- --- Room card unavailable
--- --- --- 1 --- --- --- --- Room card available
--- --- --- --- 0 --- --- --- heat pump
--- --- --- --- 1 --- --- --- cooling only
--- --- --- --- --- 0 --- --- Tempetature compensation unavailable
--- --- --- --- --- 1 --- --- Tempetature compensation available
--- --- --- --- --- --- 0 0 Cassette
AB09CS2ERA AB12CS2ERA AB18CS2ERA
BM1-1 BM1-2 BM1-3 BM1-4 BM1-5 BM1-6 BM1-7 BM1-8 Description
OFF OFF OFF -- -- -- -- -- Unit capacity: 9000
ON OFF OFF -- -- -- -- -- Unit capacity: 12000
OFF ON OFF -- -- -- -- -- Unit capacity: 18000
-- -- -- OFF -- -- -- -- Room card invalid(default)
-- -- -- ON -- -- -- -- Room card valid
-- -- -- -- OFF -- -- -- Heat pump( defult)
-- -- -- -- ON -- -- -- Cooling only
-- -- -- -- OFF OFF OFF Cassette(American)
110
