Super MatchSuper Match
Item Model 3U19FS2ERA
Function —— Cooling Heating
Rating capacity W 5400 6200
Heating pdesign(-10
℃
) W 4500
Rated power input (indoor + outdoor) W 1460 1650
Rated current input (indoor + outdoor) A 6�3 7�2
EER / COP W/W 3�7 3�75
SEER / SCOP W/W 3�57 3�62
Minimum capacity W 1500 1800
Minimum power input W 500 500
Maximum capacity W 7000 8100
Maximum power input (indoor + outdoor) W 2600 2600
Power source —— 1PH, 220-230V~, 50/60Hz
Max. running current (indoor + outdoor) A / A 11�3 11�3
Power facor(under rating power input) —— 99% 99%
Fuse size (recommended size) A 16
Outdoor unit
Compressor
Model / Manufacture —— SNB130FGYMC-L1 / MELCOM
Oil charge and type —— 500CC, FV 50S
Type —— Twin Rotary (DC inverter)
Number —— 1
Fan
Type × Number —— Axial × 1
Speed r/min High 860
Motor output/input power W 55/69
Air-ows (H/M/L) m³/h about 2000
Heat exchanger
Type / Diameter mm TP2M / 7.94
row —— 2
Face area m² about 0.52
Dimension
(WxDxH)
External mm 886/288/688
Package mm 992/408/760
Refrigerant control method —— PMVs
Defrosting method —— Automatic by reversible cycle
Crankcase heater power W none
Noise level
Sound power level dB(A) 63
Sound pressure level dB(A) 52
Weight Net / Shipping kg / kg 51/53
Piping
Refrigerant
Type / Charge kg R410A / 2�0
No need to recharge m 30
Recharge g/m 20
Pipe
Liquid mm 3* Φ6.35
Gas mm 3* Φ9.52
Connecting method —— Flared
Between I.D
&O�D
Drop between IU & OU m ≤7.5
Piping length between IU & OU m ≤10
Total liquid piping length m ≤30
Drop between indoor units m ≤1
Max. drop between IU &OU m 15(indoor unit lower than outdoor unit)
Max. drop between IU &OU m 15 (indoor unit higher than outdoor unit)
Max. drop between indoor units m 5
Max. piping length between IU & OU m 25
Max. total length m 50
1.Specification
