Haier Super Match 3U24GS2ERA User Manual

Super Match
model
3U19FS2ERA 3U24GS2ERA
5U34HS2ERA
when there is 1
indoor,the prior
stop valve is
EC
when there are 2
indoors,the prior
stop valves are
C、B 、DE
when there are 3
indoors,the prior
stop valves are
、D、CEC、B、A
when there are 4
indoors,the prior
stop valves are
E、D、C、B
when there are 5
indoors,the prior
stop valves are
E、D、C、B、A
Note: For better oil return and more reliable system, please execute as the above when
connecting indoor unit.
D
D、C
D、C、B
D、C、B、A
4U30HS2ERA
connection priority
between indoor
and stop valve
higher from down
to up
Connection cautions
81
