Super Match
AB24ES1ERA(S)
INDOOR UNIT TROUBLE SHOOTING
LED ash times
of indoor PCB
Wired
controller
display
Contents of Malfunction Possible reasons
LED4 LED3
0 1 01
Malfunction of indoor unit ambient
temper- ature sensor
Sensor disconected,or broken,or at wrong position,or
short circuit
0 2 02
Malfunction of indoor unit piping
temper- ature sensor
Sensor disconected,or brok- en,or at wrong position,or
short circuit
0 4 04 EEPROM wrong of indoor PCB
EEPROM chip disconected or broken or wrong
programmed,or PCB broken
0 7 07
Abnormal communi- cation between
indo- or and outdoor units
Wrong connection,or the wires be disconected or wrong
adress setting of indoor unit or faulty power supply or
faulty PCB or slave unit malfunction in MAXI system
0 8 /
Abnormal communi- cation between
wired controller and indoor unit
Wrong connection or wired controller broken,or PCB
faulty
0 12 0C Malfunction of drain system
Pump motor disconnected or at wrong position,or the
oat switch,disconnected
,
or at wrong position,or the
short circuit bridge disconneted
0 13 0D Zero cross sigal wrong Zero cross sigal detected wrong
0 16 10 Indoor abnormal mode operation Different from outdoor unit mode
21 15 Outdoor unit abnormal
Refer to the outdoor unit troubleshooting list
22 16 Outdoor unit abnormal
24 18 Outdoor unit abnormal
25 19 Outdoor unit abnormal
27 1B Outdoor unit abnormal
28 1C Outdoor unit abnormal
29 1D Outdoor unit abnormal
30 1E Outdoor unit abnormal
31 1F Outdoor unit abnormal
32 20 Outdoor unit abnormal
33 21 Outdoor unit abnormal
35 23 Outdoor unit abnormal
36 24 Outdoor unit abnormal
37 25 Outdoor unit abnormal
38 26 Outdoor unit abnormal
39 27 Outdoor unit abnormal
43 2B Outdoor unit abnormal
44 2C Outdoor unit abnormal
47 2F Outdoor unit abnormal
48 30 Outdoor unit abnormal
49 31 Outdoor unit abnormal
58 3A Outdoor unit abnormal
59 3B Outdoor unit abnormal
63 3F Outdoor unit abnormal
64 40 Outdoor unit abnormal
Note:
1.The outdoor failure can also be indicated by the indoor unit,the checking method as follo- ws: LED4 ash times stands for
tens digit,and LED3 ash times stands for units digit, use this bidigitate gure minus 20,then will get the outdoor error code.
For example,if the outdoor error code is 15,LED4 will ash 3 times rstly,two seconds later,LED3 will ash 5 times , and four
seconds later the process will repeat again.
2.LED4 is a yellow one on the indoor PCB,LED3 is a green one.
3.To get much more details about the out door unit failure,please refer to the outdoor unit trouble shooting list.
