Indoor Unit Installaion
Driverƽ
Torque wrench
ƽ
(17mm,22mm,26mm)
Nipperƽ
Reamerƽ
Hacksawƽ
Pipe cutterƽ
Gas leakage detector orƽ
soap-and-water solution
Hole core drillƽ
Flaring toolƽ
Spanner(17,19 and 26mm)ƽ
Knifeƽ
Measuring tapeƽ
Necessary Tools for Installation
Power Source
Before inserting power
intoreceptacle,checkthevoltage
without
fail.
The power
supply is the same as the
corresponding
nameplate.
Install an exclusive branch circuit of the power.
A receptacle shall be set up in a distance where the power
cable
can
be
reached.
Donotextendthecablebycuttingit.
Selection of Installation Place
Place, robust not causing vibration, where the body can
be
supported suf¿ciently.
ƽ
Place, not affected by heat or steam generated in the
vicinity,
where inlet and outlet of the
unit are not disturbed.
ƽ
Place, possible to drain easily, where piping can be
connectedwiththeoutdoorunit.
ƽ
Place,wherecoldaircanbespreadin a roomentirely.
ƽ
Place, nearby a power receptacle, with enough space
around.
ƽ
Place where the distance of more than lm from
televisions,
radios, wireless apparatuses
a
nd
Àuorescent lamps
can be
left.
ƽ
In the case of ¿xing the remote controller on a wall,
place
where the indoor unit can
receivesignalswhenthe
Àuore
scent
ƽ
lamps
in the room are lightened.
ƽ
ƽ
ƽ
Remote controller (1)
R-03 dry battery (2)
Mounting plate (1)
Drain hose (1)
Ø4X25 Screw
(4)
Plastic cap (4)
Accessory Parts
FOR 09K 12K
FOR 18K
Selection of Pipe
Drawing for the installation of indoor units
ƽ
Air purifying filter(Optional) (1)
more than
10cm
more than cm
more than 10cm
20
more than 60 cm
Attention must be paid to
the rising up of drain hose
ThemodelsadoptHFCfreerefrigerantR410A
Arrangement of piping
directions
Rear left
Left
Rear
right
Right
Below
System configuration
Domestic air conditioner
