3 - Description
23
Clean Water Tank
A clean water tank is integrated into the right side cover. It is accessed
for filling at the sprayers right side when entering the platform. The ball
valve is located on the valve cover below the EasyClean filter on sprayers
left side. The water in this tank is for hand washing, cleaning of clogged
nozzles etc. Only fill this tank with clean water from the well.
Capacity: approximately 20 litres.
±
WARNING! Although the clean water tank is only filled with clean
water, this water must NOT be used for drinking.
DilutionKit (optional)
The dilution kit consist of four valves added to the liquid system, enabling the rinse water to be directed from the rinse tank
into the main tank and piping to dilute spray liquid residues.
The dilution kit will ease diluting of chemicals in main tank or boom piping done from the drivers seat while driving in the
field. This can be useful when interrupting a spray job, e.g. because of rain or before the tank has to be re-filled at the farm.
The dilution kit has two functions that is selected with the optional function switch on the spray controller.
• Tank dilution: Dilute boom piping and the main tank at the same time.
• Boom dilution: Dilute the boom piping only.
÷
NOTE! Dilution of chemical residues may be required by law in certain situations before returning to the farm for filling
or cleaning. Please familiarize with current rules and follow them.
