7 - Fault finding
96
Liquid System
FAULT PROBABLE CAUSE CONTROL/REMEDY
No spray from boom when turned on. SmartValve positions are wrong. Set correct valve positions for spraying.
Suction/pressure filters are clogged. Clean suction and pressure filters.
No suction from tank. See if suction fitting in main tank sump is free of
sedimentation. Clean if needed.
Lack of pressure. Incorrect assembly. Boost valve is open.
Air in system. Fill suction hose with water for initial priming.
Too much agitation. Close the agitation valve.
Pump valves are blocked or worn. Check for obstructions and wear.
Blocked filters Clean all filters.
Defective pressure gauge. Check for dirt at inlet of pressure gauge.
Pressure dropping. Filters are clogging. Clean all filters. Fill with cleaner water. If using
powders, make sure agitation is on.
Nozzles are worn. Check flow rate. Replace nozzles, if it exceeds 10%.
Sucking air towards end of tank load. Lower pump speed (rpm).
Pressure increasing. Pressure filters beginning to clog. Clean all filters.
Formation of foam. Air is being sucked into system. Check tightness/gaskets/O-rings of all fittings on
suction side.
Excessive liquid agitation. Lower pump speed (rpm).
Check safety valve is tight.
Ensure returns inside the tank are present.
Use a foam damping additive.
Liquid leaks from bottom of the pump. Damaged diaphragm. Replace diaphragm. See relevant section.
Vibrations in system and unpleasant noise from the
pump.
Air is being sucked into system. Check for leaks, holes in hoses, tightness/gaskets/O-
rings of all fittings on the suction side.
Operating unit is not functioning, or it is having a
malfunction.
Blown fuse(s). Check mechanical function of micro switches. Use
cleaning/lubricating agent if the switch does not
operate freely.
Check motor current, max. 450-500 mA. If over,
change the motor.
Wrong polarity. Brown to positive (+). Blue to negative (-).
Valves not closing properly. Check valve seals for obstructions.
Check micro switch plate position. Loosen the screws
holding the plate a 1/2 turn.
No power. Wrong polarity. Check that brown is positive (+), blue
is negative (-).
Check print plate for dry solders or loose connections.
Check fuse holder is tight around fuse.
