5 - Operation
58
Filling of Rinsing Tank
The rinsing tank is filled via the 1” threaded connection piece at the valve system:
1. Remove the filler cap, then fit the external water hose to the threaded connection piece.
2. Engage external water pump, if any.
3. Keep an eye on the level indicator in order not to overfill the tank.
4. Stop filling and refit the cap.
Volume: approximately 450 litres.
μ
ATTENTION! Only fill rinsing tank with clean water! To avoid algae developing in the rinsing tank, always drain this
tank, if the sprayer is not in use for a longer period of time.
μ
ATTENTION! For cleaning purposes etc. the rinsing tank is also accessible via the tank lid on top of the tank.
Filling of Clean Water Tank
To fill the clean water tank:
1. Remove the tank lid
2. Fill with clean water
3. Reposition the tank lid.
For use of water:
• Turn the ball valve lever to open. The ball valve is located on the
valve cover.
The water from this tank is for hand washing, cleaning of clogged nozzles etc.
μ
ATTENTION! Only fill this tank with clean water! To avoid algae developing in the clean water tank, always drain this
tank, if the sprayer is not in use for a longer period of time.
±
WARNING! Although the clean water tank is only filled with clean water, this water must NOT be used for drinking.
