Network Video Recorder User Manual
148
The Heat Map function must be supported by the connected IP camera and the corresponding
configuration must be set.
Go to Smart Analysis > Heat Map.
Select a camera.
Select the report type as Daily Report, Weekly Report, Monthly Report, or Annual Report.
Set the Data to analyze.
Heat Map Interfaceď€
Click Counting. The results will be displayed in graphics marked in different colors.
As shown in the figure above, red color block (255, 0, 0) indicates the most trafficked area, and
blue color block (0, 0, 255) indicates the less-popular area.
(Optional) Click Export to export the statistics report in Microsoft Excel format.
