Network Video Recorder User Manual
70
Key Point Configuration
1) Configure key point parameters.
Preset: Determines the order the PTZ will follow while cycling through the patrol.
Speed: Defines the speed the PTZ will move from one key point to the next.
Duration: Refers to the duration to stay at the corresponding key point.
2) Click Apply to save the key points to the patrol.
(Optional) Click to edit the added key point.
Edit Key Point
(Optional) Select a key point and click to delete it.
(Optional) Click or to adjust the key point order.
Click Apply to save the patrol settings.
Repeat steps 3-9 to set more patrols.
Call a Patrol
Purpose
Calling a patrol makes the PTZ move according to the predefined patrol path.
Click on the quick settings toolbar of the PTZ camera’s Live View.
