Network Video Recorder User Manual
163
If you select Manual, you can edit the external port on your demand by clicking to
activate External Port Settings.
You can use the default port No., or change it according to actual requirements.
External Port indicates the port No. for port mapping in the router.
The value of the RTSP port No. should be 554 or between 1024 and 65535, while the value
of the other ports should be between 1 and 65535 and the value must be different from
each other. If multiple devices are configured for the UPnP™ settings under the same
router, the value of the port No. for each device should be unique.
Enter the virtual server setting page of router; fill in the blank of Internal Source Port with the
internal port value, the blank of External Source Port with the external port value, and other
required contents.
Each item should be corresponding with the device port, including server port, http port,
RTSP port and https port.
The virtual server setting interface below is for reference only, it may be different due to
different router manufactures. Please contact the manufacture of router if you have any
problems with setting virtual server.
Setting Virtual Server Item
Configure Ports
You can configure different types of ports to enable relevant functions.
Go to System > Network > Advanced > More Settings and configure port settings as needed.
Alarm Host IP/Port: With a remote alarm host configured, the device will send the alarm
event or exception message to the host when an alarm is triggered. The remote alarm host
must have the client management system (CMS) software installed.
The alarm host IP refers to the IP address of the remote PC on which the CMS software (e.g.,
iVMS-4200) is installed, and the alarm host port (7200 by default) must be the same as the
alarm monitoring port configured in the software.
Server Port: Server port (8000 by default) should be configured for remote client software
access and its valid range is 2000 to 65535.
