HIKVISION DS-K1T501SF User Manual

Video Access Control Terminal·User Manual
127
7.16.3 Event Playback
Purpose:
The recordings triggered by event, such as motion detection, VCA detection or behavior analysis,
can be searched for Event Playback and this function requires the support of the connected device.
Searching Video Files for Event Playback
Steps:
1. Open the Remote Playback page.
2. Select the camera and start the normal playback. Refer to Chapter 8.5.2 Normal Playback.
3. Click and the motion detection triggered recording will be searched by default.
4. Click the calendars icon to activate the calendars dialog box.
Select the start and end date and set the accurate time.
Click OK to save the searching period.
Note: In the calendar, the date which has scheduled records will be marked with and the
date with event records will be marked with .
5. Select the event type from the drop-down list and the found video files will be displayed. You
can filter the results by inputting the keyword in the Filter text field. Or you can click to go
back to the normal playback.
6. Select the video file from the search result list, and then click the icon on the video file, or
double-click the video file to play the video on the corresponding display window of playback.

HIKVISION DS-K1T501SF Specifications

General

Type	Basic access control reader
Product color	Gray
Cards capacity	50000 cards
Housing material	Metal
Keypad integrated	No
Fingerprint reader	Yes
Authentication type	Access chip/card, Biometric, Face recognition
Transaction capacity	200000
Fingerprint sensor type	Optical
Identification (1:N) time	1.5 s
False Rejection Rate (FRR)	0.01 %
False Acceptance Rate (FAR)	0.001 %
Access chip/card reader type	Contactless
International Protection (IP) code	IP65
DC current (max)	600 A
DC voltage range	12 V
Total megapixels	2 MP
Front camera type	Single camera
PC connected	-
RS-485 ports	1
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	218 mm
Width	78 mm
Height	41 mm
