User Manual of DS-TCG227-A Series Entrance/Exit Capture Unit
39
Figure 6-23 Region of Interest Settings
1. Check Enable under Fixed Area item.
2. Select the Stream Type for ROI encoding.
Each stream type only supports one ROI.
3. Select the Area Code from the drop-down list for ROI settings. There are four
fixed areas selectable.
4. Click Draw Area, and then drag the mouse to draw the region of interest on the
live video.
5. Select the ROI Level to set the image quality enhancing level. The larger the
value is, the better the image quality is.
6. Enter the Area Name for ROI as desired.
7. Click Save to save the settings.
6.4.4 Configure Record Schedule
Purpose:
You can follow the instructions to configure the scheduled recording. By default, the
