Hirschmann MACH 4000 User Manual

Network load control
26
8.4 QoS/Priority
Basic - L3P
Release 4.0 11/07
8.4.7 Setting prioritization
 Assigning the port priority
 Assigning the VLAN priority to the traffic classes
 Select the
QoS/Priority:Port Configuration dialog.
 In the "Port Priority" column, you can specify the priority (0-7) with
which the Switch sends data packets which it receives without a
VLAN tag at this port
Note: If you have set up VLANs, pay attention to the "Transparent
mode" (see on page 38 "Configuring VLANs").
enable Switch to the Priviledged EXEC mode.
configure Switch to the Configuration mode.
interface 1/1 Switch to the Interface Configuration mode of
interface 1/1.
vlan priority 3 Assign port priority 3 to interface 1/1.
exit Switch to the Configuration mode.
enable Switch to the Priviledged EXEC mode.
configure Switch to the Configuration mode.
classofservice dot1p-map-
ping 0 4
classofservice dot1p-map-
ping 1 4
Assign traffic class 4 to VLAN priority 0. Also assign
traffic class 4 to VLAN priority 1.
exit Switch to the Priviledged EXEC mode.
show classofservice dot1p-
mapping
Display the assignment.
