Operation diagnosis
8
9.2
Monitoring the device status
Basic - L3P
Release
4.0
11/07
Note: With non-redundant voltage supply, the Switch reports the absence of
a supply voltage. You can prevent this message by feeding the supply volt-
age over both inputs, or by switching off the monitoring (see on page 12
"Monitoring correct operation via the signal contact").
9.2.1 Configuring the device status
9.2.2 Displaying the device status
Select the Diagnostics:Device Status dialog.
In the "Monitoring" field, you select the events you want to monitor.
To monitor the temperature, you set the temperature thresholds in
the Basics:System dialog at the end of the system data.
enable Switch to the Priviledged EXEC mode.
configure Switch to the Configuration mode.
device-status monitor all en-
able
Include all the possible events in the device sta-
tus determination.
device-status trap enable Enable a trap to be sent if the device status
changes.
Select the Basics:System dialog.
